dolphitech dolphicam2 Ultrasonic Camera

*Please contact us for more information and demonstrations*

The dolphicam2 is the result of more than 10 years of dedicated research by dolphitech into ultrasonics and represents the leading standard for volumetric NDT. The dolphicam2 is capable of high resolution imaging and precise measurements for a wide range of material types including composites, metals and multi materials. With a straightforward, quick to deploy, user-friendly system, technicians of all experience levels can generate analysis-ready images of materials in real time for quick decision making.

Not to be confused with Phased Array, the dolphicam 2 uses a unique 2D matrix array architecture, this provides unparalleled data capture and resolution, which, when combined with a frequency range from 1.5MHz to 10MHz, gives you the ability to inspect a wide range of materials.

SOFTWARE FEATURES:
What’s on the screen? The dolphicam2 software is unique among NDT packages, designed from the ground up to complement the imaging capabilities of the platform. Ultrasonic images are shown not just using conventional signal amplitudes, but also as time of flight, opening up a world of instant, color-coded thickness mapping. This is helped further by the live 3D views, which instantly enhance visualization and can be readily interpreted by non-specialists. For maximum image quality we also provide Total Focusing Method (TFM) reconstructions, with TFM images accessible both during the acquisition itself, and on previously acquired Full Matrix Capture (FMC) data files.

Here’s a video overview of the software features on the dolphicam2: Click to Watch

HARDWARE FEATURES:
What’s in the box? dolphicam2 comes in a custom Pelicase with the chosen TRM(s), a connected Blackbox, and a Panasonic Toughpad. The TRM includes not just the transducer itself, but the Analogue to Digital Convert (ADC) electronics. This means that it connects to the Blackbox via a simple USB-C cable, removing the need for bulky multipin cables and plugs. The Blackbox itself is the heart of the system, driving the TRM while connecting to the Toughpad which runs and displays the software. The Blackbox and Toughpad are joined by a sturdy frame, and the whole system is reinforced to withstand daily site use.

DELAY LINES:
How does the sound get into my asset? Each frequency TRM comes as standard with a delay line that has been chosen to match the acoustic properties of the transducer. These include Rexolite, Aqualene and Aqualink materials, and delay line thickness options between 8-12mm. For increased flexibility you can choose a TRM without a delay line as dolphitech offer a range of replaceable models. A variety of removable pipe shoes to match different diameter pipes are also available; shoes with irrigation ports, and even a water box delay line model.

EASE OF USE:
What’s the learning curve? With 16,384 elements, you might think that the power of the dolphicam2 is difficult to harness. With the carefully designed user interface, this couldn’t be further from the truth. The system itself does the heavy lifting and lets the operator focus on the data generated. The dolphicam2 can be setup in 60 seconds, and new users without specialist NDT knowledge can be up and scanning within hours. To help users get the most out of their system, dolphitech run a range of training courses that are tailored to users’ inspection needs and prior NDT knowledge.

Here’s a video of showing the 60 second setup of the dolphiscan2: Click to Watch

PORTABILITY AND DURABILITY:
How will it perform on site? Weighing in at 3kg for the whole system, the dolphicam2 is easily portable. Combined with a continuous use battery life of 5-6 hours, this makes it well-suited to life on site. Useful features include integrated neck strap, corner bumpers, plug protection shields and an IP66 ingress protection rating. All of this and an operational temperature range of -20 to +50°C means that the dolphicam2 can be relied on for routine use in both indoor and outdoor industrial settings.

Download dolphicam2 brochure here: dolphicam 2 brochure
