Sonatest DL – Twin Compression Transducer Range

£287.99

SKU: N/A Category:

Sonatest DL dual element long reach 0° Ultrasonic Probes are available in 2MHz or 5MHz frequencies with 10mm crystal diameter available for the 2MHz option and both 5mm and 10mm crystal options available for the 5MHz option.

Features:

  • Dual normal beam compression wave contact probe
  • Semi-circular/rectangular, lead metaniobate crystal
  • Medium damped for medium bandwidth
  • Acrylic shoe facilities profiling to curved parts; * High Temp Vespel
  • Button probe case with side entry cable to facilitate inspection access
  • Integral 2m cable

Frequent Applications:

  • Aerospace
  • Bond Testing
  • Solder Joints
  • Machined Parts
  • Thickness
  • Tube & Pipe
  • White Metal
Crystal Diameter

∅5mm, ∅10mm

Frequency

2MHz, 5MHz
